AirData 150 S2 USB User Manual
60
Encryption Type: For Open & Shared authentication modes, the available encryption types
are None and WEP. For WPA, WPA2, WPA-PSK and WPA2-PSK authentication modes, the
available encryption types are TKIP and AES.
Config Methods: This attribute contains the configuration methods supported and enabled by
the selected Registrar.
Device Password ID: Device Password ID indicates the method or identifies the specific
password that the selected Registrar intends to use.
Selected Registrar: Selected Registrar indicates if the user has recently activated a
Registrar to add an Enrollee.
State: This attribute is used to indicate the current configuration state. This attribute is either
“Un-Configured” or “Configured”.
Version: This attribute is the specified WPS version.
AP Setup Locked: AP Setup Locked indicates if AP has entered a setup locked state.
UUID-E: UUID-E is the universally unique identifier (UUID) generated by the Enrollee.
RF-Bands: RF Bands indicates the available RF bands.
[Configure WPS Profiles]
The user can configure WPS profile with either PIN method or PBC method.
PIN Method:
Step 1 Î The Registrar enters the pin code generated by station.
Step 2 Î Click the “PIN” button.
PBC Method:
Step 1 Î Click the “PBC” button within 2 second while the Registrar clicks the
button.
[Manage WPS Profiles]
The Received WPS profiles are listed in the lower frame, and the listed WPS profile attributes
are SSID, MAC address, authentication type, and encryption type.
WPS profile detail information: Selecting a profile then clicking the “Detail” button brings up
the WPS profile detail information dialog.
Connect with WPS Profile: Clicking the “Connect” button will connect to AP with the select
WPS profile.
Rotate WPS profile: If there are more than two WPS profiles, clicking the “Rotate” button will
rotate to next profile and connect to AP with this profile. If the connection can’t be established,
the station will perform the WPS profile rotation repeatedly.
Disconnect from WPS AP: Clicking the “Disconnect” button will stop the WPS connection.
Delete WPS profile: Clicking the “Delete” button will delete the selected WPS profile.
