1.7 LED Indicators
IMC-1000M and IMC-1000MS have LEDs on the front face that report the condition of power, Fiber link & Speed, LAN link & Speed as well
as power or link fault.
PWR1 PWR2 Fault
Fiber
LAN
LINK/ACT
LINK/ACT
Speed
Speed
IMC-1000M(S) LED Indicators
PWR1: This green LED will light if power is connected and active at the PWR1 terminal connection.
PWR2: This green LED will light if power is connected and active at the PWR2 terminal connection.
Fault: This red LED will light if there is a power, fiber or TP fault condition.
Fiber LINK/ACT: This green LED will light when the fiber port has an optical link and flash when there is data traffic.
Fiber Speed: This two color LED will indicate the fiber speed setting. Green indicates 100M, while amber color indicates 1000M fiber speed.
LAN LINK/ACT: This green LED will light when the LAN port has a link and will flash when there is Ethernet traffic.
LAN Speed: This two color LED will indicate the UTP (LAN) speed. Green indicates 100M, while amber color indicates 1000M UTP speed. If
not lit, a LAN speed of 10M is indicated.
11
