8-30 Periodic Maintenance and Adjustment
V-belt cooling duct check hose
The V-belt cooling duct check hose is located
under the driver seat. (See pages 4-18 - 4-19
for seat removal and installation procedures.)
If dust or water collects in the V-belt cooling
duct check hose, remove the hose and clean
it.
1. V-belt cooling duct check hose
V-belt case drain plug
The V-belt case drain plug is located under
the driver seat. (See pages 4-18 - 4-19 for
seat removal and installation procedures.)
After riding in water deep enough to allow
water to enter the V-belt case, remove the
drain plug to drain any water from the case.
NOTE:
If water drains from the V-belt case after
removing the drain plug, have a service
center inspect the vehicle as the water may
affect other engine parts.
