4-8 Control Functions
unit must in in 4WD mode. The level is then
moved to expose the Yellow differential lock
button. The Yellow button must be pushed
and in the out position for the rear differential
to lock. When riding an UTV on muddy and
slippery roads or when climbing a steep hill,
make sure the 4WD lock indicator is on and
the differential is locked.
When riding on a flat road at a comparatively
high speed, adjust the settings to
“2WD/UNLOCK”. There should be no
symbols in either of the 4WD indicators.
Riding an UTV while the differential is is NOT
CAUTION:
When the selector is set to 4WD and Locked
Differential, the right 4WD symbol front axle
will have an ‘X’ in the middle. When riding
on good surfaces you should use the 2WD
drive mode. There should be no symbols
illuminated on the display
CAUTION:
If the display indicators flash or the
speedometer does not show the speed while
the UTV is in motion, Ask a dealer to check
the speed sensor and circuits.
locked (UNLOCKED) may improve the
stability and safety of the UTV operation.
Fault code indicator
When the EFI encounters faults, the ECU will
