Periodic Maintenance and Adjustment 8-37
Parking brake lever free play adjustment
Periodically check the parking brake lever
free play and adjust it if necessary.
1. Shift the drive select lever into low gear
“L”.
2. Remove the seats. (See page 4-18 -
4-19 for seat removal and installation
procedures.)
3. Remove the console. (See page 8-8 for
console removal and installation
procedures.)
4. Check the parking brake lever free play.
The maximum free play is equal to one
click of the parking brake lever. If
necessary, adjust the free play as
follows.
1. Parking brake lever free play
NOTE:
The parking brake lever must be released
when checking and adjusting the parking
brake lever free play.
5. Loosen the locknut.
To Next Page
