Control Functions 4-27
Spring preload
The spring preload, rebound damping and
compression damping forces of the front
and rear shock absorber assemblies can be
adjusted to suit the operating conditions.
NOTE:
Never turn an adjusting mechanism beyond
the minimum and maximum settings.
1. Loosen the locknut.
2. Turn the spring preload adjusting nut in
direction ⓐ to increase the spring
preload and thereby harden the
suspension, and in direction ⓑ to
decrease the spring preload and thereby
soften the suspension.
1. Locknut 2. Spring preload adjusting nut
3. Special wrench
out shock absorber assembly yourself.
Take the shock absorber assembly to an
authorized dealer for any service.
