To clean the textured polyester side

• First remove any surface dust with a dry cloth

• Use a damp cloth (not soaking wet) or even baby wipes to wipe or dab at any marks

or stains, using a gently scrubbing motion if needed for tougher stains rinsing your

cloth regularly to ensure you’re not just moving the dirt around.

• You can remove the cartridge from the frame and clean on a flat clean surface, you can

clean the screen when in situ do not use force as this can stretch the screen and the

waterproof resin, place a clean flat object / board behind whilst cleaning the area from

the opposite side.

• Wipe the fabric in one direction from top to bottom with the screen fully extended.

• Leave the screen fully extended to air dry naturally.

• Do not use bleach or any other harsh or abrasive chemicals, as this is apt to discolour

or ruin the fabric itself. Stick to water that is warm rather than hot for all these same

reasons.

• Once fully dry & clean re treat with fabric protection spray to protect against scuffs or

marks created by passing traffic in the living area.

To clean the waterproof side

• You can remove the cartridge from the frame and clean on a flat clean surface, you can

clean the screen when in situ do not use force as this can stretch the screen and the

waterproof resin, place a clean flat object / board behind whilst cleaning the area from

the opposite side.

• Use a wet soapy soft cloth or sponge to clean, using a gently scrubbing motion and

rinsing away soap with fresh clean water.

• Avoid using bleach or any other harsh or abrasive chemicals, as this is apt to discolour

or ruin the fabric itself or remove the protective waterproof layer. Stick to water that

is warm rather than hot for all these same reasons use a light soapy cleaning product.

• Once fully dry & clean re treat with waterproof shield spray to protect if required.

26. FUSION STEREO

Click for FUSION Stereo User Manual

The C16 is equipped with a MS-RA210 Fusion Head Unit located inside the door on the side of

the lounge above the switches. It comes with four speakers, two are located above the bed

and two located outside above the slide out kitchen. It features the ability to customize audio

profiles for two separate audio zones and is compatible with a smart device or Garmin watch.

Audio source options include Bluetooth, DAB+ radio, AM/FM radio, AUX and USB connections.

For more detailed user information please read carefully and refer to the respective Fusion

Owner’s Manuals provided.

FUSION-LINK WIRELESS REMOTE CONTROL APP

You can use the Fusion-Link remote control app on your compatible Apple or Android device

to adjust the stereo volume, change the source, control playback, select and manage radio

presets, and adjust some stereo settings. For information about the Fusion-Link remote

control app for compatible Apple or Android devices, go to the Apple App Store or the Google

Play™ store.
