12. AWNING

Click for FIAMMA Awning User Manual

The C16 is fitted with a Fiamma F45 S Awning. For more information on the operation and

maintenance of this awning please read carefully and refer to the respective Fiamma Owner’s

Manuals provided.

The handle and tension rafter are stored in the front lower locker area.

• Periodically check the brackets to make sure they are firmly attached (especially after

the first trip), make sure the bolts are not loose and that the holding brackets have not

shifted.

• Make sure that your awning is completely dry and clean before closing it. The

remaining humidity could cause stains. However, if you have no choice but to close the

awning when it is still wet, make sure to open it for drying within 12 hours.

• Most of the dirt is superficial and can be removed with clean water and a cloth or a

brush. If the fabric is very dirty, add some light cleaning detergent. Never use

aggressive chemical substances and never clean the fabric with a high-pressure

machine.

• Make sure that the awning perfectly rolls in; when it is, the red indicators in the front

profile ends are no longer visible. Before leaving, make sure the awning is correctly

closed. Damaged fabric will not allow the awning to perfectly roll in. Never use the

awning with a damaged canopy.

• FIAMMA recommend not to use the awning at a temperature below 0°C.

1. Use the awning handle to unwind the awning out. To avoid unnecessary strain on the

awning as well as on the caravan wall, we suggest taking out the legs about 1 metre

from the opening.
