Cube AERIUM Series User Manual

| 17 16 |
AERIUMAERIUM
12 Storage / hydration
12.1 Scope of delivery
12.2 Instruction manual
Storage system
Preparation of the storage box
To protect against damage during transport,
the storage box is supplied in a closed state
(Fig.01).
In order to open the box prior to initial use,
the locking tab must be cut open at the
marked point with a sharp blade, as shown.
(Fig.02)
Fig.01
Fig.02
Number Description
Spare
part
1 Storage-Box 34096
2 Hydration-Box MY20
34174
3 Magnetic Fit System MY20
4 Hydration Lid MY20
5 Hydration Cap MY20
6 Straw
7 Straw Holder 32765

Cube AERIUM Series Specifications

General

Frame Material	Carbon
Fork Material	Carbon
Fork	CUBE AERIUM C:62
Headset	FSA Orbit 1.5E
Stem	Cube Aerium C:68 Integrated
Handlebar	Cube Aerium C:68 Integrated
Seatpost	Cube Aerium C:68 Aero
Brakes	Shimano 105
Shifters	Shimano 105
Front Derailleur	Shimano 105
Rear Derailleur	Shimano 105
Chain	Shimano 105
Crankset	Shimano 105
Bottom Bracket	Shimano PressFit
Tires	Schwalbe One
