CUDA 2412 - 115 V Electrical Panel Parts List

Cuda 2412 • 8.914-384.0 • Rev. 5/12
25
AUTOMATIC PARTS WASHER
OPERATOR’S MANUAL
115V ELECTRICAL PANEL PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.714-820.0 Label, Control H
2
0-2412,
SC-2412D 115V 1
2 9.804-510.0 Switch, Lid/Door, 15 Amp,
Non Enclosed 2
3 8.713-328.0 Switch-Lighted Rocker Skimmer/
TT ON/OFF 2
4 8.714-057.0 Light-Indicator Red 120V,
   50"Diam 1
5 8.713-086.0 Ground-Lug 2 Hole Alum 1
6 8.714-164.0 Terminal Block - 2 Position
(Surface) BL-BL 1
7 8.714-163.0 Timer - 15 Min Spring Wound 1
8 8.713-348.0 Relay, SPDT (K36) 1
9 8.713-355.0 Relay Base 1
10 8.713-315.0 Switch-Mercury Tilt 1
11 8.713-603.0 Connector, Electrical
3 Pin Male 2
12 8.713-604.0 Connector, Elec Pin Fem 6
13 8.750-866.0 Contactor, 3 Pole 9 Amp
(Pump) 1
8.750-869.0 ▲ Contact, NC Aux, Front Mnt 1
14 8.750-864.0 Contactor, 3 Pole 16 Amp
(Heater) 1
8.750-869.0 ▲ Contact, NC Aux, Front Mnt 1
15 8.716-224.0 Holder, Fuse Block Panel MT 1
16 8.716-398.0 Terminal Block, Blue, Entrelec,
125116-01 3
17 8.716-396.0 Terminal Block, Entrelec, Gray
115-116-07 M4/6 3
18 8.716-399.0 End Cover, Entrelec, Gray
11836816 P-ON 2
19 9.800-040.0 Label, Grnd Symbol 1
20 8.716-402.0 Bridge, Fixed, Entrelec,
16897307 per 10-Pole M4/6 3
21 8.716-599.0 Terminal Grnd, Green w/yellow 1
 22 8.718-936.0 Screw,#8x1/2",Phillips,Zinc 
Plated 3
 23 8.718-937.0 Screw,#8x3/4"Phillips,Zinc 
Plated 2
 24 8.718-733.0 Screw,6/32"x5/8",Rnd,HB 4
25 8.716-375.0 Terminal, Ring Tonque 2
26 9.802-784.0 Nut, 6-32 Keps 1
 27 9.802-457.0 DinRail,35mm 7"
28 9.804-595.0 End Bracket, Entrelec 2
29 8.913-729.0 Control Panel 1
30 8.714-836.0 Fuse, 3 Amp 1
31 8.713-316.0 Clip, Mounting (For Merc.
Tilt SW) 1
32 8.713-105.0 Switch Boot, Threaded 1
33 8.913-711.0 Lid, Top 2412 1
34 8.913-721.0 Lid 2412 1
ITEM PART NO. DESCRIPTION QTY
 35 9.804-207.0 BallStud,5/16"-18UNC,
10mm 2A Stud 2
 36 9.718-980.0 Washer,5/16"FlatSAE 7
 37 9.802-776.0 Nut,5/16"ESNA,NC 6
 38 8.713-246.0 Screw,5/16"-18x1"
Socket Head 4
39 9.804-203.0 Handle, Door/Strainer 2
 40 9.802-793.0 Nut,Cage,1/4"x16GA 4
 41 9.802-700.0 Bolt,1/4"x3/4",NCHH 4
 42 9.802-802.0 Washer,1/4",Flat,SAE 6
43 8.714-379.0 Gearmotor, AC Fract 6 RPM 2412
   Drive,120V,1/2"SSShaft 1
44 9.804-247.0 Gasket, Gearmotor Paper
Fiberflex 1
45 8.714-380.0 Torque, Hub Outlaw 1
46 8.913-712.0 Torque Arm 1
47 8.913-713.0 Tip Torque, Rotation Arm 1
 48 9.802-700.0 Bolt,1/4"x3/4",NFHH 1
 49 9.802-773.0 Nut,1/4"ESNANC 3
 50 8.714-213.0 Bolt,5/16"x2"NFHH 1
51 9.804-238.0 Washer, Belleville (Disc Spring)
   .317Dx.625OD,.047"THK 3
 52 8.718-813.0 Screw,10-32"x1/2"
BH, SOC, SS 4
 53 8.718-568.0 Washer,1/4"FlatSS
Sealing Rub 4
 54 9.802-105.0 Plug,7/8"Hole 2
55 9.802-514.0 Strain Relief, STRT, LQ Tite
3231 Small 1
 56 9.802-525.0 Locknut,1/2"8463 1
 57 8.716-547.0 Connector,1/2"L/TStraight, 
Black 1
58 8.913-749.0 Lid, Hinge Stop 1
59 8.725-303.0 Capscrew, 1/4-28 x 5/8
HX AD SS 3
60 9.804-297.0 Label, Hour Meter 1
 61 9.804-242.0 Washer,FlatBronze,3/8"IDx 
   3/4"ODx1/16"THK
Thrust Bearing 2
 62 9.802-775.0 Nut,1/4"Flange,NC 12
63 9.804-224.0 Decal, Caution, Check Water
Levels, All Models 1
64 9.804-294.0 Knob, Timer, Black 2
65 9.802-515.0 Strain Relief LQ Tite 1
 66 9.802-748.0 Screw6/32"x3/8"Rnd 1
 67 8.716-019.0 Channel1" 12"
 68 8.716-021.0 Cover1" 12"
69 8.716-400.0 End Cover Blue 1
70 8.713-357.0 Timer, 30 Min 1
▲ Not Shown
