CUDA 2412 - 208 V;230 V Electrical Panel Parts List

Cuda 2412 • 8.914-384.0 • Rev. 5/12
27
AUTOMATIC PARTS WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
1 8.714-821.0 Label, Control, H
2
O-2412,
230V 1
2 9.804-510.0 Switch, Lid/Door, 15 Amp Non
Enclosed 1
3 8.713-328.0 Switch, Lighted Rocker Skimmer/
TT ON/OFF 1
4 8.714-057.0 Light, IndicatorRed120V,.50"D 1
5 8.713-086.0 Ground, Lug 2 Hole Alum 1
6 8.714-164.0 Terminal Block, 2 Pos
(Surface) BL-BL 1
7 8.712-832.0 Timer, 60 Min Spring Wound
w/Hold Wash 1
8 8.713-348.0 Relay, SPDT (K36) 1
9 8.713-355.0 Relay, Base 1
10 8.713-315.0 Switch-Mercury Tilt 1
11 8.713-603.0 Connector, Electrical 3 Pin Mal 2
12 8.713-604.0 Connector, Electrical Pin Fem 6
13 8.714-290.0 Contactor, Gen Purpose, 2 Pole
230V, 30 Amp 1
14 8.750-866.0 Contactor, 3 Pole, 9 Amp 1
 15 8.714-839.0 Plug,PlasticBlack1/2" 1
16 8.716-398.0 Terminal Block, Blue Entrelec
125116-01 3
17 8.716-396.0 Terminal Block, Entrelec, Gray
115-116-07 M4/6 3
18 8.716-399.0 End Cover, Entrelec, 11836816
P-ON Gray 2
 19 9.802-776.0 Nut,5/16"ESNANC 6
20 8.716-402.0 Bridge, Fixed, Entrelec, 16897307
Per 10 Pole M4/6 3
21 8.716-599.0 Terminal, Ground, Green/Yellow 2
 22 8.718-936.0 Screw,#8x1/2",Phillips,Zinc 
Plated 11
 23 8.718-937.0 Screw,#8x3/4"Phillips,Zinc
Plated 6
24 8.718-733.0 Screw, 6/32"x5/8",RndHBMCH 6
25 9.800-040.0 Label, Ground Symbol 1
26 9.802-784.0 Nut, 6-32 Keps 1
 27 9.802-457.0 DinRail,35mm 7"
28 9.804-595.0 End Bracket, Entrelec 2
29 8.941-092.0 Control Panel 1
30 8.713-316.0 Clip, Mounting 1
 31 8.718-980.0 Washer,5/16"Flat 7
32 8.713-105.0 Switch Boot, Threaded 1
33 8.913-711.0 Lid Top 2412 1
34 8.913-721.0 Lid 2412 1
 35 9.804-207.0 BallStud5/16"-18UNC10mm
2A Stud 2
36 8.713-287.0 Fuse, 12 Amp 2
37 9.804-294.0 Knob, Timer Black 3
208V, 230V ELECTRICAL PANEL PARTS LIST
ITEM PART NO. DESCRIPTION QTY
 38 8.713-246.0 Screw,5/16"-18x1"SktHd 4
39 9.804-203.0 Handle, Door/Strainer 2
 40 9.802-793.0 Nut,Cage,1/4"x16Ga 4
 41 9.802-700.0 Bolt,1/4"x3/4",NCHH 4
 42 9.802-802.0 Washer,1/4"FlatSAE 6
43 8.714-379.0 Gearmotor, AC Fract 6 RPM
   2412Drive120V1/2"SSShaft1
44 9.804-247.0 Gasket, Gearmotor Paper
Fiberflex 1
45 8.714-380.0 Torque Hub, Outlaw 1
46 8.913-712.0 Torque Arm 1
47 8.913-713.0 Tip Torque Rotation Arm 1
 48 9.802-700.0 Bolt,1/4"x3/4",NCHH 1
 49 9.802-773.0 Nut,1/4"ESNANC 3
 50 8.714-213.0 Bolt,5/16"x2",NFHH 1
51 9.804-238.0 Washer, Belleville (Disc Spring)
   .317Dx.625OD.047"THK 3
 52 8.718-813.0 Screw,10-32"x1/2"
BH, SOC, SS 4
53 8.718-568.0 Washer,1/4"FlatSSSealingRub 4
 54 9.802-105.0 Plug,7/8"Hole 2
55 9.802-514.0 Strain Relief, STRT, LQ Tite, Sm 1
 56 9.802-525.0 Locknut,1/2"8463 1
 57 8.716-547.0 Connector,1/2"L/TStraightBlk1
58 8.913-749.0 Lid, Hinge Stop 1
59 8.725-303.0 Capscrew, 1/4-28 x 5/8
HX HD SS 3
60 9.804-297.0 Label, Hour Meter 1
 61 9.804-242.0 Washer,FlatBronze,3/8"IDx3/4"
   ODx1/16"ThkThrustBearing2
 62 9.802-775.0 Nut,1/4"FlangeNC 12
63 8.713-768.0 Connector, Electrical Pin Male 6
64 8.716-375.0 Terminal, Ring Tongue 2
65 9.804-224.0 Decal, Caution, Check Water
Level, All Models 1
66 8.713-290.0 Fuse Block (H2PR) 2 Pole 2
67 8.712-833.0 Timer, 12 HR Spring Wound
Heater 1
68 8.716-875.0 Transformer, 200VA,
230-460V/115V
8.716-895.0 Transformer, 200VA, 208V 1
69 8.713-078.0 Fuse, 2 Amp FNM-2 1
70 8.713-286.0 Fuse, Class 2 Amp 2
71 8.713-369.0 Fuse, 25 Amp 2
72 8.713-731.0 Connector, Elecl, 6-Pin Fem 1
 73 9.802-784.0 Screw,6/32"x3/8" 1
74 8.716-400.0 End Cover, Blue, Entrelec 1
75 9.802-515.0 Strain Relief, STRT, LQ Tite 1
