CUDA 2412 - Exploded Front View Parts List

Cuda 2412 • 8.914-384.0 • Rev. 5/12
29
AUTOMATIC PARTS WASHER
OPERATOR’S MANUAL
EXPLODED FRONT VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.913-719.0 Tank Assy 2412 1
 2 8.706-328.0 Pipe,Plug1/4"Galv. 1
 3 8.706-350.0 Pipe,Cap1/2"Galv. 1
 4 8.706-349.0 Pipe,Cap1-1/2"Galv. 1
5 9.802-776.0 Nut, 5/16 ESNA 2
6 8.915-388.0 Seal, Bulb Type (12G) Nitrile,
   SideProle 48"
7 9.804-185.0 Latch-Vise Action Side
Acc Cover 1
 8 8.711-919.0 Caster,Fixed,2-1/2"
Polywheel 2
 9 8.711-920.0 Caster,Swivel,2-1/2"x1-1/8" 
Polyolefin 2
 10 8.713-246.0 Screw,5/16"-18x1"
Socket Head 2
11 9.804-203.0 Handle, Door/Strainer 1
12 8.913-705.0 Debris, Tray Assy 1
13 8.913-727.0 Door Assy, Sump Access 1
14 8.712-777.0 Nozzle, 50°, #3 5
15 8.714-202.0 Nozzle, 80°, #3 3
 16 8.706-047.0 Pipe,Bushing1-1/4"to1"
Black 1
17 8.706-081.0 Cap, Pipe 1 NPT 150WP
Non PL 1
ITEM PART NO. DESCRIPTION QTY
 18 8.706-320.0 Cap,3/4"BlackPipe 1
 19 8.930-155.0 Elbow,45°,3/4"Galv. 1
 20 8.706-340.0 Pipe,Barbed,MaleNPT3/4" 
Black 2
 21 9.802-261.0 Hose,3/4"Push-on,per/ft 24"
22 9.803-629.0 Clamp, Screw, #16 2
 23 8.720-002.0 SprayPipe1"x10" 1
24 8.913-706.0 Assy., Upper Spray Bar 1
25 8.913-724.0 Turntable Assy 1
26 9.804-259.0 Thrust Bearing 1
27 8.904-660.0 Decal, Keep Hands Clear
When Closing Lid 1
28 9.804-223.0 Decal, Oper Inst, All Models 1
29 9.801-126.0 Label, Cuda 24 x 6 1
30 8.913-702.0 Oil Bucket (Opt) 1
 31 9.802-773.0 Nut,1/4"ESNA,NC 18
 32 9.802-802.0 Washer,1/4"Flat,SAE 18
33 8.705-962.0 Ring, Containment (Opt) 1
34 8.718-813.0 Screw, 10/32 x 1/2, BH,
SOC, SS 3
35 8.718-568.0 Washer, Sealing 3
36 9.804-567.0 Nut, 10/32 ESNA 3
 37 8.718-980.0 Washer,5/16"Flat 2
 38 9.801-132.0 Label,CudaIcon6" 1
39 8.725-296.0 Washer, Bullet Hinge
8mm Pin Brass 2
40 8.725-297.0 Washer, Bullet Hinge
6mm Pin Brass 2
 41 9.802-775.0 Nut,1/4",FlangeNC 2
42 8.751-325.0 FilterMediol,1/4",
   2"x12"x1" 1
43 9.800-013.0 Label, Assembled USA
Intended for indoor use. 1
44 9.800-034.0 Label, Clear Lexan 1
45 N/A Label, UL/ETL 1
46 9.804-361.0 Decal, Patent Number 1
47 8.706-150.0 Elbow, 1" 3
48 8.706-191.0 Elbow, 1"x3/4" 1
