CUDA 2412 - Exploded Rear View Parts List

Cuda 2412 • 8.914-384.0 • Rev. 5/12
31
AUTOMATIC PARTS WASHER
OPERATOR’S MANUAL
EXPLODED REAR VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.714-540.0 Gas Spring, Strut 70#
(4514QF) (115V) 2
8.724-076.0 Gas Spring 90# (7227SA)
(230V) 2
 2 9.804-207.0 BallStud,5/16"-18UNC10mm
2A Stud 2
 3 9.802-776.0 Nut,5/16"ESNA,NC 2
 4 8.718-987.0 Washer,5/16"FlatSS
Sealing Rub 2
 5 8.716-542.0 Connector,1/2"L/TStraight,
Black 2
6 9.802-514.0 Strain Relief, STRT, LQ Tite
3231 Small 1
 7 9.802-802.0 WasherFlat1/4" 4
8 9.802-448.0 Conduit, Water Tight,
   Flex1/2" 36"
9 9.802-448.0 Conduit, Water Tight
   Flex1/2" 22"
10 8.714-187.0 Heating Element, 1.8KW/120V/
   1PH,(115V1PH)1"NPT,MS
   9"Lw/Seal 1
8.712-813.0 Heating Element, 4.5 KW/230V/
   1PH,1"NPTMSw/Seal
(208V 1 PH, 230V 1 PH) 1
11 8.713-593.0 Thermostat, Snap Disc 180° F
1 PH 1
12 9.804-119.0 Switch, Magnetic Reed Sensor
NC 1
13 9.804-118.0 Switch, Magnetic Reed Sensor,
NO 1
14 9.804-120.0 Magnet, Reed Sensor Target 1
 15 8.731-134.0 Screw,4-40x1/2"SlottedP/H
   M/SZinc 1
 16 8.718-847.0 Nut,4-40Keps,Zinc 1
17 8.714-226.0 Float, PLY, Cylindrical
   2"Diax3-3/4" 1
18 8.913-717.0 Float Holder 1
19 8.930-331.0 Cover, Heater Element 1
 20 9.802-094.0 Foamstrip1/8"x1/2"
   AdhesiveBack 30"
ITEM PART NO. DESCRIPTION QTY
 21 9.802-700.0 Bolt,1/4"x3/4",NC 4
 22 8.718-762.0 Screw,8-32x1/2",MPH
RDH PL 1
 23 9.802-423.0 Cord16/3 60"
24 9.804-140.0 Decal, Warning 1
25 8.713-656.0 Connector, Electrical, 3 Pin
Female 1
26 8.713-768.0 Connector, Electrical Pin Male 3
27 9.800-016.0 Label, Disconnect Power
Supply 3
28* 8.715-398.0 Pump Scot, 1/2 HP
115/230V 1 PH 1
29 9.802-517.0 Connector, 1/2 L/T, 90°, Black 1
30 9.802-105.0 ▲Plug,7/8"Hole 1
 31 8.706-199.0 Elbow,1-1/4",90°Street
Galv. 2
32 8.706-341.0 Pipe, Barbed Male NPT
   1-1/4"Galv. 2
 33 8.714-828.0 Hose,1-1/4"x6-1/2"Precut 
Black 200 PSI 1
34 8.709-081.0 Clamp, Screw, #28 4
 35 9.804-244.0 Hose,1-1/4"x14-1/2"Precut, 
200 PSI 1
 36 9.802-807.0 Washer,3/8"SAEFlat 4
 37 9.802-779.0 Nut,3/8"ESNA,NC 4
 38 9.802-793.0 Nut,Cage1-4"x16GA 4
39 9.804-374.0 Decal, Keep Dry 2
40 8.712-896.0 ▲ Scoop, Detergent, White
16 oz. 1
▲ Not Shown
* 8.713-359.0 Seal Kit
8.713-360.0 O-Ring
