C and E Models
Cuddeback C & E models are very similar, but with
these notable dierences.
✓ C models feature exchangeable ash modules.
By removing the ash bezel the user can replace
the ash module as desired. is allows the user
to convert the camera to strobe (white ash),
IR or Black Flash® by changing modules.
✓ e C model ash modules are also more
powerful than the built-in illuminators in the
E models.
erefore, the C models will have
longer
ash illumination range.
See Appendix C: C Camera for instruction on
replacing ash modules.
Install batteries
Install batteries by removing the 2 battery door
thumb screws and removing the battery door. Insert
8 AA batteries
as shown. Make sure to observe the
correct polarity. BATTERIES CAN EXPLODE,
LEAK ACID, OR IGNITE IF INSERTED
INCORRECTLY. Aer batteries are inserted correct-
ly, reinstall the battery door and fully tighten the 2
thumb screws.
E Model
Long Range IR (shown)
C Model with Black Flash® module in camera and
interchangeable Long Range IR and White Flash
(color) modules along side.
IMPORTANT
Be sure to
insert batteries
with correct
polarity!
+
–
+
–
+
–
+
–
Notice unique battery
orientation
