All Purpose Cooler Overview 3
Cat. No. 01023621
All Purpose Overview
Cold Tank
The cold tank is manufactured from 304 Stainless Steel which is non-corrosive. The cold water temperature is preset at
approximately 41°F (5°C) by the factory. The capacity of the cold tank is 1 gallon (4 liters). The cold tank temperature is
controlled by a thermostat that is set at the factory.
PCB
The PCB (Printed Circuit Board) is the control unit for the All Purpose Cooler. It is responsible for the selection and
dispensing of water. The PCB drives an LED which informs the user of the status of the unit. The PCB has a power on
indicator and also indicates to the user what option of water is currently selected by changing color.
Compressor
The compressor uses R134a non-ozone depleting refrigerant gas. The compressor is controlled by an electromechanical
thermostat, which controls the temperature of the water in the cold tank unit.
Water Pipe and Fittings
All water connection fittings are approved to NSF standard 61. The machine is connected to the water supply by a 1/4”
female bulkhead fitting. The entire internal water circuit and all components which come in contact with water are food
grade NSF / WRAS approved.
Water Valves
Water dispensing to the customer is achieved by means of a 24V DC electrical solenoid valve. The valves are energized
each time the customer pushes the dispense button for a drink. DC voltage is used for safety.
Plastic Panels
The molded panels are made from recyclable ABS plastic. All the ABS plastic panels are UV resistant and meet the stan-
dards of CE and UL.
