Culligan MEDALLIST SERIES Service Manual

8 CULLIGAN MEDALLIST SERIES
™
TABLE 4 - SALT DOSAGE
Capacity 160 lb. Brine Tank 250 lb. Brine Tank 375 lb. Brine Tank
    "A"Dimension  "A"Dimension   "A"Dimension
Salt Capacity Secondary (Only) Secondary Primary Secondary Primary
Dosage 8" ft
3
30 ft
3
45 ft
3
in. (cm) in. (cm) in. (cm) in. (cm) in. (cm)
4 18,300 X X 7-3/4 19.7 6-5/8 16.8 4-5/8 11.7 5-1/2 14.0 3-1/2 8.9
5 20,000 20,000 20,000 9-1/2 24.1 8 20.3 6 15.2 6-1/2 16.5 4-1/2 11.4
6 22,000 22,500 23,500 11-1/4 28.6 9-3/8 23.8 7-3/8 18.7 7-1/2 19 5-1/2 14
7 23,200 24,400 26,500 13 33 10-7/8 27.6 8-7/8 22.5 8-1/2 21.6 6-1/2 16.5
8 24,100 25,700 29,000 14-3/4 37.5 12-1/4 31.1 10-1/4 26 9-1/2 24.1 7-1/2 19
9 25,100 27,000 31,300 16-1/2 42 13-5/8 34.6 11-5/8 29.5 10-1/2 26.7 8-1/2 21.6
10 26,100 28,300 33,300 18-1/4 46.3 15 38.1 13 33 11-1/2 29.2 9-1/2 24.1
11 26,800 29,400 35,000 20 51 16-3/8 41.6 14-3/8 36.5 12-1/2 31.7 10-1/2 26.7
12 27,500 30,500 36,500 21-3/4 55.2 17-3/4 45.1 15-3/4 40 13-1/2 34.3 11-1/2 29.2
13 X 31,500 38,400 21-1/2 59.7 19-1/8 48.6 17-1/8 43.5 14-1/2 36.8 12-1/2 31.7
14 X 32,500 39,200 25-1/4 64.1 20-1/2 52.1 18-1/2 47 15-1/2 39.4 13-1/2 34.3
15 X 33,300 40,400 — — 21-7/8 55.5 19-7/8 50.5 16-1/2 42 14-1/2 36.8
16 X 34,100 41,200 — — 23-1/4 59 21-1/4 54 17-1/2 44.5 15-1/2 39.4
17 X 35,000 41,800 — — 24-5/8 62.5 22-5/8 57.5 18-1/2 47 16-1/2 42
18 X X 42,400 — — 26 66 24 61 19-1/2 49.5 17-1/2 44.5
19 X X 42,900 — — 27-3/8 69.5 25-3/8 64.5 20-1/2 52.1 18-1/2 47
20 X X 43,500 — — 28-3/4 73 26-3/4 68 21-1/2 54.6 19-1/2 49.5
3. Treated Water Volume Set Point
Calculate the treated water volume set point using the following information:
• Softening capacity — Grains (based upon salt dosage setting).
• Compensated hardness of water supply — Grains Per Gallon
• Estimated daily water usage — Gallons Per Day (refer to Table 5)
TABLE 5 - Daily Water Usage
 PersonsinHousehold GallonsPerDay
2 150
3 225
4 300
5 375
6 450
7 525
8 600
9 675
10 750
Example - Meter: Softener Model Medallist 2M
Capacity @ 9 lb. Salt Dosage: 25,100 Grains
Compensated Water Hardness: 19 Grains Per Gallon
Estimated Daily Water Usage: 300 Gallons Per Day
Treated Water Volume Set Point = — Water Usage
Softening Capacity 25,100 Grains
Divide by Compensated Hardness ÷ 19 Grains per Gallon
Result is total number of gallons 1,321 Gallons
of soft water per regeneration
Subtract daily Water Usage (needed — 300 Daily Water Usage (One Day Supply)
as a reserve to ensure continuous 1,021 Gallons
soft water until regeneration occurs).
Round down to nearest ten for Treated
Water Volume Set Point 1,020 Gallon Setting
Set "CAPG" to 102
Softener Capacity
Compensated Hardness

Culligan MEDALLIST SERIES Specifications

General

Type	Water Softener
Flow Rate	Up to 12 gallons per minute
Resin Type	High-capacity resin
Dimensions	Varies by model
Weight	Varies by model
Tank Material	Fiberglass
