Part No. 4801-5331 Rev 2-2015 Evolution 1200 44 of 65
8.3 Connecting Temperature Sensor to Evolution 1200
Warning!
Tape Shields To Prevent Bare Wires From Touching!
WARNING!
LOW VOLTAGE!
Keep Separate From
High Voltage Wires!
Inset A
NOTE: Other sensors are
connected similarly.
Inset A
PCB 186
