Cumberland Evolution 1200 Series - Connecting the Powertrak and EV S; To the Evolution 1200

Part No. 4801-5331 Rev 2-2015 Evolution 1200 49 of 65
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HOT
NEUT.
LOWER
GND.
HOT
OUT
CLOSE
IN
OPEN
IN
COM
UPPER
8.10 Connecting the PowerTrak and EV S
3
to the Evolution 1200
Cumberland
NOTE: If curtain is setup to pull curtain up to open, then reverse wires connected to "OPEN" and "CLOSE"
terminals.
NOTE: Only 1 Power Trak can be connected to each Power Trak outlet. If Additional Power Traks are needed,
Then use of relay boxes is necessary to separate the load.
NOTE: All PowerTrak units will connect the same.
Inset A
WARNING!
 Keep High Voltage (Or AC) Separate
From Low Voltage Wires!
 Do not perform modifications or wiring
with voltage applied!
Inset B
Vent Override
PT Hot
Open
Close
PowerTrak
Con
t
Ho
t
PT
Ho
t
PT
Open
Vent Override
Com
!
Inset A
Inset C
Unit #2 Tunnel
PCB – 188 Power Ventilation
Inset C
Evolution S
3
Circuit Board
Inset B
Vent Override
NOTE: If connecting the S
3
to a
relay box instead of PowerTrak,
Cut and discard the four
components shown.
Tunnel Override
Cumb
erlan
d
