Part No. 4801-5307 Rev 2-15 Evolution 3000 and 3001 42 of 70
(10) GPAD12 thru GPAD15 – For HHI Service Technician Use ONLY.
General Purpose A/D Readings:
As shown on the Diagnostics screen in Section 7.14, there is a section with four displays labeled
GPAD12, GPAD13, GPAD14, and GPAD15. These values represent the data being received from
the I/O Expansion Board, if equipped. These values will be used to troubleshoot your controller
by a qualified service technician in the case that a problem occurs with your I/O Expansion board.
The following tables give you an idea of the range of values and what they represent.
GPAD12 & GPAD13 -- Feed Level Sensor Inputs
Range
Status
Cause
0-24
Bin is full
Feed is on or above proximity
rod.
25-57
Loss of Echo
Bin may be empty or a sensor
error
58-239
Sensing Feed
Value should be based on level
of feed with 58 being
approximately full.
240-255
Error
Could represent empty but
probably a defective sensor.
GPAD12 = Bin 1
GPAD13 = Bin 2
GPAD14 -- Current Sensors for Auger 1, Auger 2, Belt 1
Motor Status
Range
Auger 1
Auger 2
Belt 1
0-115
On
On
On
116-124
Off
On
On
125-136
On
Off
On
137-151
Off
Off
On
152-169
On
On
Off
170-194
Off
On
Off
195-224
On
Off
Off
225-255
Off
Off
Off
GPAD15 -- Current Sensors for Belt 2, Belt 3, Belt 4
Motor Status
Range
Auger 1
Auger 2
Belt 1
0-115
On
On
On
116-124
Off
On
On
125-136
On
Off
On
137-151
Off
Off
On
152-169
On
On
Off
170-194
Off
On
Off
195-224
On
Off
Off
225-255
Off
Off
Off
(11) Soft Resets - For HHI Use Only. Indicates that the control is sensing environmental problems which
can cause controller malfunctions.
(12) Voltage Resets - For HHI Use Only.
(13) Hard Resets - For HHI Use Only.
