Cumberland Evolution 3000 - Connecting the Powertrak to the Evolution 3000 & 3001

Part No. 4801-5307 Rev 2-15 Evolution 3000 and 3001 51 of 70
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HOT
NEUT.
LOWER
GND.
HOT
OUT
CLOSE
IN
OPEN
IN
COM
UPPER
9.10 Connecting the PowerTrak to the Evolution 3000 & 3001
NOTE: If curtain is setup to pull curtain up to open, then reverse wires connected to "OPEN" and "CLOSE"
terminals.
NOTE: Only 1 Power Trak can be connected to each Power Trak outlet. If Additional Power Traks are needed,
Then use of relay boxes is necessary to separate the load.
NOTE: All PowerTrak units will connect the same.
Inset A
Unit #2 Vents
Unit #2 Vents
COM
Close
Open
Inset B
Inset B
J
1
J
2
Hired - Hand
B. Crider
D 1
D 2
D 3
D 4
Copyright (c) 2000
PCB 167 Rev ‘0’
C
O
M
O
pen
C
lose
U
nit #1 (Vents)
C
O
M
O
pen
C
lose
U
nit #2 (Tunnel)
+12V
Open
U1
Relay Control
Close
U1
Open
U2
Close
U2
HIRED-HAND
R L Y 1 R L Y 2
R L Y 3
R L Y 4
Inset A
PCB – 167 Power Ventilation
WARNING!
Keep High Voltage (Or AC)
Separate From Low Voltage
Wires!
Evolution 3000 / 3001
