Part No. 4801-5307 Rev 2-15 Evolution 3000 and 3001 53 of 70
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HOT
NEUT.
LOWER
GND.
HOT
OUT
CLOSE
IN
OPEN
IN
COM
UPPER
9.12 Connecting the PowerTrak and EV Back-Up to the Evolution 3000 & 3001
NOTE: If curtain is setup to pull curtain up to open, then reverse wires connected to "OPEN" and "CLOSE"
terminals.
NOTE: Only 1 Power Trak can be connected to each Power Trak outlet. If Additional Power Traks are needed,
Then use of relay boxes is necessary to separate the load.
NOTE: All PowerTrak units will connect the same.
Inset C
Unit #2 Vents
Inset A
WARNING!
 Keep High Voltage (Or AC) Separate
From Low Voltage Wires!
 Do not perform modifications or wiring
with voltage applied!
Inset B
Vent Override
PT Hot
Open
Close
Inset A
PowerTrak
Cont
Hot
P
T
Hot
P
T
Ope
n
Vent Override
Com
!
Evolution Back-Up Circuit Board
Inset B
Vent Override
NOTE:
If connecting the
Back-Up to a
relay box instead
of PowerTrak,
Cut and discard
the specific two
or four
components
shown as needed.
Tunnel Override
Evolution 3000 / 3001
Inset C
PCB – 167 Power Ventilation
J
1
J
2
Hired - Hand
B. Crider
D 1
D 2
D 3
D 4
Copyright (c) 2000
PCB 167 Rev ‘0’
C
O
M
O
pen
C
lose
U
nit #1 (Vents)
C
O
M
O
pen
C
lose
U
nit #2 (Tunnel)
+12V
Open
U1
Relay Control
Close
U1
Open
U2
Close
U2
HIRED-HAND
R L Y 1 R L Y 2
R L Y 3
R L Y 4
