TABLE 1 : MODEL- WISE RECOMMENDATIONS (DIESEL ENGINE)
Engine Model Rating Typical * Exhaust Exh. Fuel Lub Coolant Total Air Radiator Radiator
(0.8 pf) Room Size pipe size Gas flow supply/ Oil Capacity (Ventilation + breathing) Fan flow Core
Heat Exchanger
max. 4 (No. of return System requirement for Genset in Area
L X W X H Bends banks x pipes Capacity Genset Min. raw * Typical * Raw
Max. flow per upto Max. amb. Max. amb. room water flow cooling water
Length bank) 10 mtrs. above below at engine tower pipe
10 mtrs. (H for HE 40
o
C40
o
C HE capacity size
Min. ID Min. ID R for Radiator) (rise 5
o
C) (rise 10
o
C) H X W (wbt 26
o
C) (ID)
KVA m x m x m No. x mm No. x lt/sec mm lt lt lt./sec. lt./sec. lt./sec. m x m lt./min. TR mm
QSK60-G4 2000 12.5 x 7.5 x 6.5 2 x 325 2 x 2805 50 400 550 (H) 750 (R) 41915 22090 32285 2.3 X 2.4 1760 200 125
QSK60-G3 1875 12.5 x 7.5 x 6.5 2 x 325 2 x 2700 50 400 550 (H) 750 (R) 38525 20310 32285 2.3 X 2.4 1760 200 125
KTA50-G8-I 1500 12.0 x 7.0 x 6.5 2 x 250 2 x 2220 25 177 320 (H) 555 (R) 34955 18275 28400 2.2 X 1.95 1300 150 125
KTA50-G3 1250 12.0 x 7.0 x 6.5 2 x 250 2 x 1910 25 177 310 (H) 440 (R) 31475 16420 27375 2.1 x 2.0 1300 125 125
KTA38-G5 1000 11.0 x 7.0 x 6.5 2 x 250 2 x 1460 25 145 199 (H) 260 (R) 26980 14050 23855 1.9 x 1.8 900 100 100
KTA38-G2-I (2300) 750 9. 0 x 6.0 x 5.0 2 x 200 2 x 1245 25 118 230 (H) 300 (R) 21795 11395 22655 1.9 x 1.65 625 70 100
VTA28-G5 625 8.5 x 6.0 x 5.0 2 x125 2 x 945 20 95 212 (H) 250 (R) 17770 9270 22655 1.9 x 1.65 540 60 75
VTA28-G3 600 8.5 x 6.0 x 5.0 2 x 125 2 x 930 20 95 210 (H) 240 (R) 17405 9060 18880 1.9 x 1.6 480 60 75
KTA19-G4 500 8.5 x 5.5 x 5.0 1 x 200 1 x 1600 20 55 125 (H) 175 (R) 14410 7480 20280 1.48 x 1.58 ** 385 + 150 60 75 + 40
KTA19-G3 450 8.5 x 5.5 x 5.0 1 x 200 1 x 1460 20 55 125 (H) 165 (R) 13110 6800 13000 1.48 x 1.58 385 45 75
KTA1150-G 380 8.0 x 5.5 x 5.0 1 x 125 1 x 1095 20 55 80 (H) 115 (R) 12070 6255 10385 1.14 x 1.22 300 35 65
NTA14-G3 380 8.0 x 5.5 x 5.0 1 x 125 1 x 1055 20 39 45 (H) 76 (R) 11110 5750 10385 1.58 X 1.48 300 35 65
NTA855-G2 BC 320 7.5 x 5.0 x 5.0 1 x 125 1 x 990 20 39 40 (H) 95 (R) 9385 4855 10070 1.18 X 1.22 ** 275 + 125 35 65 + 40
NT855-G6 BC 285 7.5 x 5.0 x 5.0 1 x 125 1 x 1160 20 39 47 (H) 80 (R) 8975 4650 10070 1.08 X 1.27 275 30 50
NT855-G5 BC 250 7.5 x 5.0 x 5.0 1 x 125 1 x 960 20 39 47 (H) 80 (R) 8285 4300 10070 1.08 X 1.27 240 25 50
NT855-G4 BC 225 7.5 x 5.0 x 5.0 1 x 125 1 x 860 20 39 47 (H) 80 (R) 7305 3795 10070 1.08 X 1.27 240 25 50
6CTAA8.3-G1-I 200 6.5 x 4.5 x 3.5 1 x 100 1 x 610 15 24 28 (R) 6245 3225 7385 0.7 x 1.0 NA NA NA
6CTA8.3-G2-I 180 6.5 x 4.5 x 3.5 1 x 100 1 x 550 15 24 27 (R) 6035 3115 5540 0.73 X 0.74 NA NA NA
6CTA8.3-G1-I 160 6.5 x 4.5 x 3.5 1 x 100 1 x 540 15 24 27 (R) 5565 2880 5540 0.73 X 0.74 NA NA NA
6CT8.3-G2-I 140 6.5 x 4.5 x 3.5 1 x 100 1 x 470 15 24 27 (R) 4955 2555 5540 0.73 X 0.74 NA NA NA
6BTA5.9-G2-I 125 6.0 x 4.0 x 3.5 1 x 100 1 x 225 15 14.3 25 (R) 4920 2525 4000 0.7 X 0.7 121 — 45
6BT5.9-G1-I 82.5 6.0 x 4.0 x 3.5 1 x 100 1 x 225 15 14.3 22 (R) 3420 1760 2880 0.7 X 0.7 NA NA NA
S3.8-G7 62.5 6.0 x 3.5 x 3.0 1 x 75 1 x 190 10 9 13 (R) 2450 1260 1880 0.6 X 0.6 NA NA NA
S3.8-G6 50 6.0 x 3.5 x 3.0 1 x 75 1 x 150 10 9 11 (R) 2090 1075 1880 0.5 X 0.5 NA NA NA
S3.8-G5 45 6.0 x 3.5 x 3.0 1 x 75 1 x 150 10 9 11 (R) 2090 1075 1880 0.5 X 0.5 NA NA NA
S3.8-G4 40 6.0 x 3.5 x 3.0 1 x 75 1 x 150 10 9 11 (R) 1715 890 1880 0.5 X 0.5 NA NA NA
S3.8-G3 35 6.0 x 3.5 x 3.0 1 x 75 1 x 115 10 9 11 (R) 1420 730 1880 0.5 X 0.5 NA NA NA
S3.8-G2 30 6.0 x 3.5 x 3.0 1 x 75 1 x 115 10 9 11 (R) 1240 640 1880 0.5 X 0.5 NA NA NA
X2.5-G2 25 4.0 x 1.5 x 2.0 1 x 50 1 x 75 10 6.5 7.5 (R) 1060 542 1250 0.4 X 0.4 NA NA NA
X2.5-G1 20 4.0 x 1.5 x 2.0 1 x 50 1 x 75 10 6.5 7.5 (R) 930 475 1250 0.4 X 0.4 NA NA NA
X1.7-G1 15 4.0 x 1.5 x 2.0 1 x 50 1 x 50 10 5 6 (R) 670 345 1050 0.4 X 0.4 NA NA NA
* Typical Sizes, actual specifications may change as per site condition. ** Separate raw water connections for LTA and main circuit. NA = Not Applicable
Note : Lub oil for C Series / N14 engines is CH4 15W-40 and for all other engines CF4 15W-40.
