CUMMINS DG set - Pre-Installation Check List

26
PRE-INSTALLATION CHECK LIST
Yes No
Customer Name :_______________________DG Set Rating___________ ESN :_________
Is room layout / system drawings available with customer/GOEM? If yes attach one copy to this
checksheet.
Genset Location
Location : Ground Level / Basement ( First / Second ) / Roof top / Acoustic enclosure
Genset should be located considering local wind flow direction. There should not be obstruction to
natural wind flow.
Genset should be located away from dusty atmosphere (acidic fumes/dust/fibers/chemical etc.)
Room Layout
Size : Length ___________ Breadth___________ Height__________
For multiple sets ensure minimum distance between DG sets as per guidelines
Proper & sufficient openings in engine room for ventilation as per guidelines.
Remarks:
Room Ventilation :
Recommended openings for radiator cooled engines. Actual size at front & rear___________
Provision for forced ventilation in HE cooled engines
Remarks:
Foundation:
Size: Length______________ Breadth______________ Height______________
DG Set placement provides area for service personnel to move around the DG set
Remarks:
Air system :
Heavy duty air cleaners for dusty environment
Fresh air ducting for fibrous conditions to prevent early choking of air cleaner
Suitable orientation of Radiator cooled sets to avoid fiber/ Dust entry in DG room
Exhaust system:
Correct size of exhaust piping as per model /KV Rating to ensure back pressure within specs.
Pipe size.____________
Silencer should preferably be located outside DG Room.
Insulation & lagging of exhaust pipes/ silencer inside DG Room (except elbow & bellow).
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
