Provide shortest exhaust pipe routing with minimum number of bends
Thimble in side wall
Exhaust pipe should be properly supported to avoid load on Bellow/Turbo
Exhaust outlet orientation in wind flow direction
Chimney / Common ducting as per recommendations
Remarks:
Cooling system:
No immediate obstruction in front of radiator
Location of cooling tower to ensure shortest possible pipe routing with minimum number of bends
Size of raw water piping to ensure flow as per recommendations ______________
Raw water as per recommendations
HE raw water plumbing as per recommendations for multiple set installation
Ensure use of strainer / Cleaners / Valves / Instrumentation in raw water piping
Cooling tower selection as per recommendations / site conditions.
Remarks:
Tank location as per recommendation (should not obstruct free movement)
Shortest fuel pipe routing with minimum number of bends
Gravity feed of minimum 300 mm (12 inch) above fuel pump inlet line for critical start AMF sets
D. G. Control Panel:
Location should not obstruct flow of fresh air
Should not obstruct movement
Proper visibility
Cabling as per recommendation
NOTE: Following Installation discrepancies to be corrected, prior to Genset installation.
1) ..........................................................................................................................................
2) ..........................................................................................................................................
3) ..........................................................................................................................................
4) ..........................................................................................................................................
The above recommendations have bee discussed.
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
(Name, Signature & Designation) (Name, Signature & Designation) (Name, Signature & Designation)
OEM Engineer Dealer Engineer Customer
