Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual 7
Product Specifications
The INLINE™ 7 Data Link Adapter is configured with the following
specifications:
Feature
Data
Physical Dimensions 6.75" x 3.75" x 1.06" 
(171 mm x 95 mm x 27 mm)
Weight
8 oz. (0.22 kg)
Power Requirements 6 - 32 VDC @ 350 mA maximum
Operating Temperature
0 to +70 °C
API Driver TMC RP1210A, RP1210B, and RP1210C
compliant
Vehicle Protocols Supported • J1708/J1587
• J1939 (250K, 500K, or 1 MB)
• CAN (125K, 250K, 500K, 1 MB)
(3 CAN channels with Auto Baud)
• ISO 9141
• ISO 14230 (KWP2000)
• ISO 15765
USB Communication USB Device, version 1.1
USB Connector
Latching USB Mini-B
Wired Communication Automotive A to Mini-B USB cable 13 ft.
(4 m) maximum
Wireless Communication • Bluetooth
®
Class 1 adapter (up to 100
m range)
• Dual band Wi-Fi (802.11 a/b/g/n)
Vehicle Connector High Density D-sub 26-pin Male (HD26M)
