2
TABLE OF CONTENTS
Safety Alerts ....................................................................................3
Important Safety Information
....................................................4, 5
Specifications – 747 Omni™ Bender
.............................................6
Features
........................................................................................6, 7
Grounding Instructions
................................................................... 8
Transporting
..................................................................................... 9
Set Up
.......................................................................................10, 11
Shoe Set-Up
.............................................................................12, 13
Bend Angle Limit Switch and Stop Switch
..........................14, 15
Support Roller Return Spring
......................................................16
1/2" to 1
1
⁄4" Bending Instructions ..........................................17, 18
1
1
⁄2" and 2" Bending Instructions ...........................................19, 23
1/2" to 2" Bending Instructions – PVC Coated Rigid
...........24, 25
Bend Degree Pointer Adjustment
................................................ 26
Stub Up Bending Information
...................................................... 27
Springback Charts
.........................................................................28
Offset Bending Information and Charts
................................29, 30
Maintenance
............................................................................ 31-33
Troubleshooting
......................................................................34, 35
Exploded Views and Parts List
.............................................. 36-45
Electrical System Diagram
...........................................................46
