OFFSET BENDING INFORMATION AND CHARTS
continued
TO LOCATE THE CENTER TO CENTER DISTANCE OF OFFSET
BENDING MARKS OTHER THAN THOSE LISTED IN CHART D, USE THE
FOLLOWING MULTIPLIERS: MULTIPLY THE HEIGHT OF THE OFFSET
DESIRED BY 3.86 ON 15° BENDS, 2 ON 30° BENDS, AND 1.4 ON 45° BENDS.
CONDUIT SIZE
1/2"
3/4"
1"
1-1/4"
1-1/2"
2"
"X"
2-1/2 3-1/16 3-1/16
4
4-3/4 4-3/4
CHART D
OFFSET
HEIGHT
2"
4"
6"
8"
10"
12"
14"
16"
18"
20"
22"
30° 45°15°
MAX
CONDUIT
SIZE
CENTER
TO
CENTER
MAX
CONDUIT
SIZE
CENTER
TO
CENTER
MAX
CONDUIT
SIZE
CENTER
TO
CENTER
3/4"
1-1/2"
2"
3/4"
1-1/2"
2"
1"
1/2"
1-1/4"
1"
1-1/2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
2"
7-3/4"
61-13/16"
15-7/16"
23-3/16"
30-7/8"
38-5/8"
46-3/8"
54-1/16"
69-9/16"
77-1/4"
85"
7-5/16"
11-15/16"
15-15/16"
19-15/16"
23-15/16"
27-15/16"
31-15/16"
35-15/16"
39-15/16"
43-15/16"
8-5/16"
11-1/16"
13-13/16"
16-5/8"
19-7/16"
22-1/4"
25-1/16"
27-15/16"
30-3/4"
FIGURES ARE APPROXIMATE
CHART E
END OF CONDUIT
TO START OF BEND
OFFSET
HEIGHT
ANGLE
ROTATE CHAIN
TENSIONER UPWARD
TO TIGHTEN CHAIN
CHAIN TENSIONER
HEX SCREW
1/4" MAX
LARGE
HOLES
SMALL HOLES
LARGE DRIVE STUD
LARGE DRIVE STUD
SMALL DRIVE STUD
SMALL DRIVE STUD
BENDING SHOE
