½" TO 2" BENDING INSTRUCTIONS – PVC COATED RIGID
1. Select and mount the optional 1/2" to 2" PVC Coated Rigid bending shoe
(Part #2-3200-7) as described in the shoe set-up section on pages 12 and
13.
NOTE: The optional PVC Coated Rigid bending shoe (Part #2-3200-7) is a
single shoe that will bend the full range of PVC Coated Rigid conduit from
1/2" to 2".
2. Next, install the 1/2" thru 2" pin-on roller support (Part #2-4300-7) as
shown below.
1/2" thru 2" PVC Coated
Rigid conduit uses
the pin-on roller support
(Part #2-4300-7)
Attach the pin-on roller support as shown below:
