Current Tools Omni 747 - Limit Switch and Contact Issues

35
TROUBLESHOOTING — CONTINUED
Problem Cause Diagnosis Cure
7. Pointer passes
bend angle
limit switch in
the clockwise
direction.
Magnet damaged,
missing or greater
than 1/2" from bend
angle limit switch
Visual check Replace the
magnet(s) or the
pointer
Bend angle limit
switch malfunction
Magnet is installed
and within 1/2" of bend
angle limit switch
Replace bend angle
limit switch
