OPERATING INSTRUCTIONS
— CONTINUED
29
NEVER allow the rope to slip on a rotating capstan for more than a
couple of seconds. The rope will wear in that spot and the rope could
break under pressure. If you need to stop the pull, turn the cable puller
off and tie the rope off to hold it in place until you restart your pull.
WARNING
This cable puller is equipped with an anti-reversing pawl. The pawl will
make a clicking sound when the capstan is rotating. if you can not hear
the clicking sound as the capstan rotates, immediately turn the cable
puller off and do not use until repaired.
WARNING
Keep all body parts, hair, loose clothing, etc. away from rotating parts
and pinch points. Keep hands away from capstan.
DO NOT wrap rope around any body parts. DO NOT wrap rope around
wrists.
ALWAYS keep the tailing rope away from the operator’s feet.
WARNING
5. Once the puller ready light mounted in the electronics box is lit, depress the foot
switch to activate the puller. As the rope is tailed, it should mound on the floor
between the operator and the cable puller.
6. Release pressure off of the foot switch to stop the puller. Turn the cable puller
circuit breaker switch to the OFF position when the pull is completed.
NOTE: If for any reason you need to stop during a pull, release pressure on
the foot switch, turn the cable puller OFF and tie off the tailing rope to hold
it in place.
NOTE: The Model 1450 Cable Puller is equipped with a circuit breaker
switch. If the amperage rating of the breaker is exceeded the puller
will switch off. Before restarting the pull, allow the motor to cool and
determine the cause for the overload condition. Correct before restarting
the pull.
NOTE: There is a built-in delay when switching the unit on or when
changing speeds. The puller ready light in the electronics box will
illuminate green when the puller is ready for use.
