4 — MONITOR MENU
MONITOR MENU
Through its Monitor menu, the programmer provides access to real-time data
during vehicle operation. This information is helpful during diagnostics and
troubleshooting, and also while adjusting programmable parameters.
MONITOR MENU
DISPLAY
VARIABLE UNITS DESCRIPTION
Heatsink Temp °C Heatsinktemperature.
Throttle % Throttlerequest,aspercentageoffullthrottle.
Duty Cycle % Controller’sPWMoutput,aspercentage
of programmed Max Speed.
Cap Voltage V Voltageofcontroller’sinternalcapacitorbank
at B+ busbar.
A2 Voltage V Voltageoncontroller’sA2busbar.
Battery Voltage V Battery voltage.
Motor Voltage V Voltagebetweencontroller’sB+andM-busbars.
Motor Open On/Off Status of motor connection.
Plug Braking On/Off Statusofplugbrakingfeature.
