4b — CONTROLLER INFO MENU
CONTROLLER INFORMATION MENU
is menu provides ID and version numbers for your controller hardware and
software.
CONTROLLER INFORMATION MENU
DISPLAY
VARIABLE RANGE DESCRIPTION
Model Number 0 – 4294967295 Model number. For example, if you have a
Model_Number 0 – 4294967295 1236E controller with the model number
0x3464 0x00
1236E-4521, the Model Number variable will
have a value of 12364521.
Serial Number
0 – 4294967295 Serial number. For example, if the serial
Serial_Number 0 – 4294967295 number printed on your controller is
0x1018 0x04 15045L.11493, the Serial Number variable
will have the value of 11493.
Mfg Date Code
 0–32767 Controllerdateofmanufacture,withtherst
Manuf_Date 0 – 32767 two digits indicating the year and the last
0x3466 0x00 three indicating the day. For example, if the
serial number printed on your controller is
15045L.11493, the Mfg Date Code variable
will have the value of 15045 (45th day of
2015).
Hardware Version 0 – 32.767 The hardware version number uniquely
Hardware_Ver 0 – 32767 describes the combination of power base
0x3467 0x00
assembly and the logic, cap, and IMS board
assemblies used in the controller.
OS Version
0 – 65535 Version number of the operating system
OS_Ver 0 – 65535 software that is loaded into the controller.
0x346A 0x00  Thisvariablespeciesthemajor version
numberofthecontroller’soperatingsystem.
Build Number 0 – 65535 Build number of the operating system
Build_Number 0 – 65535 software that is loaded into the controller.
0x346B 0x00  Thisvariablespeciestheminor version
numberofthecontroller’soperatingsystem.
SM Version 0 – 327.67 Version number of the Start Manager
SM_Ver 0 – 32767 software that is loaded into the controller.
0x332B 0x00
Param Blk Version
0 – 327.67 Version number of the parameter block that
Param_Blk_Ver 0 – 32767 is loaded into the controller.
0x3468 0x00
VCL App Version
0 – 327.67 Version number of the VCL application
VCL_App_Ver 0 – 32767 software that is loaded into the controller.
0x3463 0x00
This value is set in the VCL program by
assigning a value to the VCL_App_Ver
variable.
Vehicle Serial Number
0 – 4294967295 ProvidedforOEMuseanddenition.
Vehicle_Serial_Number 0 – 4294967295
0x393D 0x00
