COMMUNICATION PROFILE OBJECTS
The objects found in the 1000h CAN Object address range are shown below
in Table 1.
Table 1 Communication Prole Objects
INDEX SUB-INDEX ACCESS BYTE 5 BYTE 6 BYTE 7 BYTE 8 DESCRIPTION
1000h 00h RO 0 0 0 0 Device Type.
1001h 00h RO 0 0 0 0 Error Register.
1008h 00h RO 1 0 3 0 Model Number.
Four ascii characters; = 1030.
1009h 00h RO 0 0 0 1 Hardware Version.
Four ascii characters.
100Ah 00h RO 0 0 0 1 Software Version.
Four ascii characters.
101Bh 00h RO 5 0 0 0 Identity Object.
Number of entries = 5.
01h RO 49h 43h 00h 00h Identity Object.
Vendor ID = 00004349h.
02h RO 1 0 3 0 Identity Object.
Model Number; four ascii characters.
03h RO 0 0 0 1 Identity Object.
Model Number sequential code;
Four ascii characters.
04h RO 0 0 0 0 Identity Object.
Serial Number.
