8 — DEVICE MONITOR OBJECTS
The data recorded per the events in Bytes 42 – 51 is as follows.
BATTERY CYCLE EVENT
BYTE DESCRIPTION END OF CHARGE POWER DOWN
byte42 Batterycyclenumber(LSB). EoC_V_LSB PowerDown_sec
byte43 Batterycyclenumber(MSB). EoC_V_MSB _min
byte44 TotalAhchargeforbatterycycle(LSB). EoC_I_LSB _hour
byte45 TotalAhchargeforbatterycycle(MSB). EoC_I_MSB PowerDown_Day
byte46 TotalAhdischargeforbatterycycle(LSB). [notused] _Month
byte47 TotalAhdischargeforbatterycycle(MSB). [notused] _Year
byte 48 Max temperature for battery cycle. [not used] [not used]
byte 49 Min temperature for battery cycle. [not used] [not used]
byte50 5Hrratecapacityavailable(LSB). [notused] [notused]
byte51 5Hrratecapacityavailable(MSB). [notused] [notused]
Retrieving historical records
Historical records are generated for four different events (see page 23). To find
the precise historical data location where the data cycle has been recorded, use
the following steps. This way data for any cycle number can be retrieved without
a search through all the historical records. The retrieval starts with a request
to 5302h to find the record number. (See also, chart at bottom of page 23.)
The Acuity response to this request is as follows.
INDEX SUB-INDEX ACCESS BYTE 5 BYTE 6 BYTE 7 BYTE 8 DESCRIPTION
5302h 00h RO Cycle number Cycle number 0 0 Read historical record.
(LSB) (MSB)
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
40h 02h 53h 00h Historical Historical 0 0
Record Record
Number Number
(LSB) (MSB)
After the historic record number is received, specific details for that record can
be retrieved, using the SDO object Historic Record Request (5300h), along
with the appropriate sub-index.
INDEX SUB-INDEX ACCESS BYTE 5 BYTE 6 BYTE 7 BYTE 8 DESCRIPTION
5300h 00..15h RO Record number Record number 0 0 Read historical record.
(LSB) (MSB)
