9 — SPECIFICATIONS
SPECIFICATIONS
The specifications for the Curtis Model 1030 Acuity are presented in Table 4.
CAN TERMINATION CAN
 MODELNUMBER VOLTAGERANGE RESISTOR120Ω CONNECTOR
1030-304 24 – 48 VDC no Bullet
1030-310 24 – 48 VDC no Deutsch
1030-306 24 – 48 VDC yes Deutsch
1030-308 24 – 48 VDC yes Bullet
1030-305 72 –144 VDC no Bullet
1030-311 72 –144 VDC no Deutsch
1030-307 72 –144 VDC yes Deutsch
1030-309 72 –144 VDC yes Bullet
Table 4 Specications: 1030 Acuity
Electrical
Operating voltage range 24 – 48 VDC; 72 –144 VDC
Electricalisolation 500VAC,perUL583
Transients IEC6100-4-4,testlevel2
Reverse voltage Acuity will not be damaged if connected to the battery
protection with inverted polarity.
Shortcircuit Allinputsandoutputs(exceptCANbus)shallwithstand
protection continousshortcircuittoB–orB+.
CANbus Isolation Eliminates ground loops that can cause component
damage as well as data errors due to differences in ground
potentials among the nodes on the CANbus.
Environmental
Operating/storage –30°C to 55°C
temperature range
Humidity 100%condensing,perIEC60068-2-30,Db
Protection IP67,perEN60529
Vibration IEC60068-2-6,Fc
Shock IEC60068-2-29,Eb
Chemicalresistance Immunetotheeffectsofcontactwithbatteryelectrolyte,
 hydraulicuid,water,bakingsoda.
EMC
Emission EN55022ClassB(componenttest):EN12895(vehicletest)
Immunity EN61000-4-3(componenttest):EN12895(vehicletest)
ESD EN61000-4-2(componenttest):EN12895(vehicletest)
Regulatory Approvals
UL(pending) Recognitionorcomponentlisting(UL583)
9

Curtis Acuity 1030 Specifications

General

Brand	Curtis
Model	Acuity 1030
Category	Measuring Instruments
Language	English
