CUSHCRAFT R9 - Assemble Traps; Assemble 40 Meter Spoke Hats

11
#9-ASSEMBLETRAPS
18”
(45.7cm)
BT2
BT1
BE
410
410
411
BT1 BT1 TRAP 1
17/20METER
BT2 BT2 TRAP 1
30METER
BE R8 TUBE 7/8"x16" 1
BE (2.3x41cm)
410 030410 SSWORM 7/16"-1" 2
CLAMP (1.1x2.5cm)
411 030411 SSWORM 9/16"x1-1/4" 1
CLAMP (1.4x3.2cm)
KEY
P/NDISPLA
Y DESCSIZEQTY
FIGURE L
Frequency(MHz) Length(In)(cm)
7.025 20"(50.8)
7.050 18.5"(47.0)
7.100 16"(40.6)
7.150 13"(33.0)
Frequency(MHz) Length(In)(cm)
7.200 10"(23.4)
7.250 7"(17.8)
7.300 5"(12.7)
Assembletraps(BT1)and(BT2)asshownincalloutofFig."L".Slide
thisassemblyintotoptube(BD)ofmainradiatorassemblyuntilithits
thescrewsofX-hatassemblyandsecureitwithwormclamp(411).
R9
40Meter TuneChart
1/8 AL spoke4places
cap
S68places.Looselyfitthescrewsandnutsintothe
ring.Inserttherodsintotheringandtightenthescrews.
Theringsareshownfurtherapartthantheyareonthe
loadingsectionforillustrationonly. Youdonotneedto
unboltthemfromthetube.Installthespokecapsonthe
tipsoftherods.
40MeterCapacityHatRing
#10-ASSEMBLE40METERSPOKEHATS
