CUSHCRAFT R9 - Assemble Metal Clamps on Radiator

64
15-3/8”
(39.1cm)
LOWERBRACKET
SITSFLUSHON
BASE ASSEMBLY
87
64
99
87
99
7
#5-ASSEMBLEMETAL
CLAMPSONTORADIATOR
Astheantennaradiatorsitsonworkhorsesorpairofchairsplacethe
aluminumstubclamps(99)onradiatoraccordingtheFig."H".Make
surethe clamps arealigned as shown.Leave the hardware on clamps
(64,87)slightlyloosetoallowyouinsertthestubtubeslater.
R9
FIGURE H
64 014764 SSMACHINE #8-32x2-1/4” 4
SCREW (5.7cm)
87 014387 SSNYLON #8-32 4
HEXNUT
99 205099 ALUMINUM 2
STUBCLAMP
KEY P/NDISPLAY DESCSIZEQTY
