CUSHCRAFT R9 - Base to Mast Assembly; Feedline Connection

14
FigureN
FigureO
#11-BASETOMASTASSEMBLY
726 195726
“V”
Bracket 4
118 010118 SSHEXNUT 5/16"-#18 8
119 010119 SSSPLIT LOCK 5/16" 8
WASHER
404 010404 U-BOLT 5/16-18x3-1/4" 2
(6.2x8.2cm)
405 010405 U-BOLT 5/16-18x4-1/2" 2
(6.2x11.4cm)
4079 194079 MOUNTING 1
PLATE -
326 290326 WARNING 1
LABEL -
405
404
119
726
726
4079
326
AttachtheantennabasetoyourmastasshowninFigureN.Firstattach
themountingplate(4079)withU-bolts(404),aluminumV-blocks(63),and
nut(389)totheantennabase. Thebottomoftheplateshouldshouldbe
evenwiththebottomoftheantennatoleaveroomfortheradialclamping
system. Affix danger label (326) to the antenna sothatit is easy to see.
Whenattaching mounting platetothemastusethe(405)U-bolts,mast
clamps(726),andnut(389).
404
Linebottom
ofplateup
withbottom
ofantenna.
#12-FEEDLINE
TheR9isdesignedforusewith50Ohmcoaxialcableterminatedwitha
PL-259connector. Theshortestlengthofcablewillhavetheleastloss.
A connectorbootisincludedforusewithyournewantenna(figureO).
SlidethebootoverthecablebeforeattachingyourPL-259.Coatonlythe
outsideconnectorthreadsandshellwithsiliconegrease.Donotcoatthe
centerpinorreceptacle. AfterthePL-259isfirmlyscrewedontothe
antennaconnector,slidethevinylbootovertheconnectorandagainstthe
connectorbracketforagoodweather-tightconnection. Aftertheantenna
isonthemast,tapethefeedlinetothemast. Ifyouplantoinstallthe
antennainasaltyorcorrosiveenvironment,youmaywanttoconsider
coatingitwithaclearmarinevarnishorequivalentafteritisassembled.
115 050115 CONNECTOR 1
BOOT
116 240116 SILICONE 1
PACKAGE
SILICONEGREASE
cushcraft
115
SILICONE
(116)
DONOT COAT
CENTERPIN
WITHSILICONE
!
SILICONEGREASE
cushcraft
KEY P/NDISPLAY DESCSIZEQTY
KEY P/NDISPLAY DESCSIZEQTY
118
4PLACES
118
4PLACES
4PLACES
389
R9
118
405
726
726
119
4PLACES
4PLACES
Note: Applyliquidsoaporanti-seizecompoundto
threadsofU-boltsbeforeattachingnuts.
