CUSHCRAFT R9 - Assemble 80 Meter Spoke Hat

#11-ASSEMBLE80METER
SPOKEHAT
R9
1/8 AL spoke48” (8places)
6-32x3/8(8placesincluding2alreadymounted)
Loosenthepre-installedscrewsandinsertthe
restofthescrewsandnutsloosely.Insertthe
spokesandtightenalleightscrews.Installspoke
capsonthetipsoftheRods.
80meterspokes
40meterspokes
80Meterloadingcoil
40Meterloadingcoil
20-R9-CA
408 TUBECAP 5/8
InsertBF3inchesintotheloadingcoil
andsecurewithhoseclamp.Slidethe
5/8tubecapontopofCA
12
6-32W/lock
S6
W6
