CUSHCRAFT R9 - Page 3

2
R8
R9
KEY PART#DESCRIPTION QTY
BA Baseassembly 1
BB R8 TubeBB1-1/4"x72"(3.17x182.9cm) 1
BC R8 TubeBC1-1/8"x72"(2.9x182.9cm) 1
BD R8 TubeBD1"x36"(2.5x91cm) 1
BE R8 TubeBE7/8'x16"(2.3x40.5cm) 1
SA R8StubSA 3/8"x52"(0.9x132cm) 1
SC R8StubSC3/8"x48"(0.9x121.9cm) 1
SD R8StubSD3/8"x48"(0.9x121.9cm) 1
SE R8StubSE1/4"x12"(0.6x30cm) 1
SF R8StubSF3/8"x72"(0.9x182.8cm2
SG R8StubSG3/8"x43-1/2"(0.9x110.5cm)1
SH R8StubSH3/8"x68"(0.9x173cm) 1
BT1 BT1 Trap17/20Meter 1
BT2 BT2 Trap30Meter 1
MN9 R9MatchingNetwork 1
XHR40 40"X-HatRod 2
09 010009 #8-32x5/8"SSRHMS 12
11 010011 #8-32SSHexNut 18
26 190026 AluminumBracket 2
28 190028 AluminumHalfWasher 2
32 902832 49"Whip& Tip Assembly 7
726 195726 U-bolt “V” Bracket 4
64 014764 #8-32x2-1/4"SSMachineScrew 4
73 194173 RadialRing “L” Bracket 4
74 194174 RadialRing 2
79 010079 #8-32x1/2"SSRHMachineScrew 4
87 014387 #8-32xSS/NylonHexNut 23
96 010096 #8-32x3/8"SSRHMS 4
99 205099 AluminumStubClamp 2
105 055105 1/4"BlackPlasticCap 4
115 050115 ConnectorBoot 1
116 240116 SiliconePackage 1
118 010118 5/16-18SSHexNut 8
119 010119 5/16SSSplitLockWasher 8
120 010120 #8-32x2"SSRHMS 1
160 190160 MatchingNetworkBracket 1
220 010220 #10-24SSHexNut 1
231 010231 #8-32x1-3/4"SSRHMS 5
232 010232 #8-32x2-1/2"SSRHMS 6
233 010233 #10SSSplitLockWasher 1
326 290326 DangerLabel 8
404 010404 U-BoltSS5/16-183-1/4(2-7/16C-C) 2
405 010405 U-boltSS5/16-184-1/2(2-7/16C-C) 2
407 030407 WormClampSS7/32"-5/8" 10
410 030410 WormClampSS7/16"-1" 3
411 030411 WormClampSS9/16"-1-1/4" 4
412 030412 WormClampSS11/16"-1-1/2" 1
413 030413 WormClampSS3/4"-1-3/4" 1
428 902428 GroundStrap 1
657 194657 AluminumL Bracket 6
940 360940 #8 AluminumFlatWasher 12
941 011941 #8SSSplitLockWasher 18
4079 194079 AluminumMountingPlate 1
5072 205072 4-HoleInsulator 1
5096 205096 3-HoleInsulator 1
5097 205097 2-HoleInsulator 1
TubeCap5/8"
765-1062
408
656-0375S 6-32x3/8ScrewS6
S6
6-32NutWithlock
15
15
705-0632S-K
10-24x½SS
500158
S7
4
KEY
PART#DESCRIPTION
QTY
S8020-R9-4880MeterSpokes8
S4020-R9-3640MeterSpokes4
LC111-R9-LC80-40loadingCoil Assembly1
BF20-R9-CA Tube AL 5/8.035x36” 1
75455624 TubeCap1/8” 12
4141916503/4tubeclamp1
