GENERAL SPECIFICATIONS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MODEL: SHUTTLE™ 4
TYPE: GAS POWERED PERSONNEL CARRIER
MODEL YEAR: 2012
Part No:. 618851
Engine: 13 hp (9.7 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
l Valve Train: Ov erhead valve l Fuel System: Fixed float bowl with remote pulse fuel pump
l Lubrication: Pressurized oil system, spin-on oil filter l Ignition: Electronic spark/magneto
l Balancer: Internal counter rotating balance shaft l Air Cleaner: Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 CCA, 60 minute reserve)
Drive Train: Automatic, continuously variable transmission (CVT)
Brakes: Dual rear wheel mechanical self-adjusting drum brakes.Single point park brake release with self-compensating system
Transaxle: Differential with helical gears, ground speed governor, forward/reverse
Performance
Ov erall Length 133.5 in (339.0 cm) Seating Capacity 4 Person
Ov erall Width 46.5 in (119.0 cm) Dry Weight 896 lb (405 kg)
Ov erall Height (No Canopy) 48.6 in (123.0 cm) (Top of steering wheel) Curb Weight 936 lb (425 kg)
Ov erall Height (With Canopy) 72.0 in (183.0 cm) Bed Load Capacity 400 lb (180 kg)
Wheel Base 93.5 in (237.0 cm) Vehicle load capacity 1200 lb (540 kg)
Front Wheel Track 34.2 in (86.7 cm) Outside Clearance Circle 25.5 ft (7.8 m)
Rear Wheel Track 38.0 in (97.0 cm) Intersecting Aisle Clearance N/A
Gnd Clearance @ Differential 4.3 in (11.0 cm) Speed (Level Ground) 16 mph ± 0.5 mph (26 kph ± 0.8 kph)
Cargo Box Width (inside) 42.5 in (108.0 cm) Towing Capacity N/A
Cargo Box Length (inside) 32.0 in (80.0 cm)
Steering & Suspension
Cargo Box Depth (inside) 11.5 in (29.0 cm) Steering Self-compensating reduction rack and pinion
Cargo Box Capacity 9 cu ft (.25.0 m3) Front Suspension Leaf springs with hydraulic shock absorbers
Cargo Box material Wood Stake Sides Rear Suspension Leaf springs with hydraulic shock absorbers
Vehicle Power Service Brake Rear wheel mechanical self-adjusting drum
Power Source 4 Cycle 24.5 cu in (401 cc). Low Emission Parking Brake Self-compensating, single point engagement
Valve Train Single Cylinder OHV Front Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Horsepower (kW) 13 hp (9.7 kW) Exceeds SAE J1940 Std. Rear Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Electrical Sy stem Starter/Generator. Solid State Regulator
Body & Chassis
Battery (Qty, Type) One, 12 Volt Maintenance Free Frame Welded steel. DuraShield™ powder coat
Key or Pedal Start Pedal Front & Rear Body & Finish Injection molded TPO
Air Cleaner Industrial Rated Dry Filter Seat Pod & Finish Fiberglass & Gelcoat
Lubrication Pressurized Oil Sy stem Standard Color Champagne
Oil Filter Spin-On
Cooling System Air Cooled
Fuel Capacity 5.8 Gallon (22.0 L) tank
Drive Train Continuously variable transmission (CVT)
Transaxle Differential with helical gears
Gear Selection Forward - Reverse
Rear Axle Ratio 11.42:1 (Forward) 15.78:1 (Reverse)
Some items shown may be optional equipment
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW
Dimensions
Specications are subject to change without notice
* Field installed accessories may require installation charges
Noise & Vibration
Sound pressure; continued A-weighted equal to or
less than 76 db(A)
Highest RMS value of weighted acceleration is 1.23 m/s
2
Highest RMS value of weighted acceleration is less than
2.5 m/s
2
The uncertainty of measurement is 0.69 m/s
2
Noise
Vibration, WBV
Vibration, HAV
