ELECTRICAL SYSTEM
Fig. 7 Electrical Accessories
TURN SIGNAL
HEAD LIGHT
&
Rear
Fender
WHT to BLK from Harness - Both Sides
BLK to BLU/WHT from Harness - Both Sides
RED to WHT from Harness - Driver Side
RED to YEL from Harness - Passenger Side
RED TO BRN from Harness - (W/O Turn Signals)
TAIL LIGHTS
To Next Page
