Cushman SHUTTLE 4X - Periodic Service Schedule

Page A-5
Repair and Service Manual
B
GENERAL INFORMATION & ROUTINE MAINTANENCE
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
PERIODIC SERVICE SCHEDULE
 - CHECK C&A - CHECK & ADJUST CL - CLEAN R - REPLACE
*Use only distilled or purified water that is free of contaminants to fill batteries.
REMARKS
before each use DAILY
20 rnds/20 hrs 100 miles/160 kms MONTHLY
60 rnds/60 hrs 300 miles/500 kms QUARTERLY 125 rnds/125 hrs 600miles/1000 kms SEMI-ANNUAL 250 rnds/250 hrs 1200miles/2000 kms ANNUAL 5 YEARS PAGE
Tires - pressure, condition of tires & rims
  
Hardwares and Fasteners - loose or missing
   
Reverse Warning Indicator
   
Overall Vehicle Condition
   
Batteries - state of charge, condition, loose terminals,
corrosion, hold down & hardware

CL CL CL CL
Batteries* - check electrolyte level, fill if required C&A C&A C&A C&A
Brakes - smooth operation of pedal, Fluid , stopping
distance
   
Brakes - aggressive stop test, does brake hold on a hill

Accelerator - smooth operation
   
Wiring - loose connections, broken or missing insulation

Charger Receptacle - clean connections CL CL CL CL
Steering Assembly - excessive play, loose or missing
hardware

Tie Rods - excessive play, bent rods, loose or missing
hardware

Rear Axle - oil leakage, noise, loose or missing
hardware

Rear Axle - drain & replace fluid R
Front Suspension - strut oil leakage, excessive play in
hubs or kingpins, worn bushings, loose or missing
hardware

Front Wheel Alignment - unusual tire wear, missing lug
nuts.
C&A C&A C&A
Rear Suspension - shock oil leakage, worn bushings,
loose or missing hardware

Motor Coupling - Add Anti - Sieze compound
(Apporx 1 tablespoon)
20,000
AMP-
Hrs
Fig. 4 Periodic Service Schedule
