Page Q-3
Repair and Service Manual
B
HANDHELD DIAGNOSTICS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Menu Submenu 1 Submenu 2 Submenu 3 Data Range
Default
Value
Units
Program
Profile Selection 1 - 5 - -
Freedom Enable ON/OFF OFF
Profiles
1 - Airport
Speed 4 - 8 6 mph
Accel Selection 1 - 2 1 -
Braking Selection 1 - 2 1 -
2 - Golf Flat
Speed 10.2 - 14.8 14.8 mph
Accel Selection 1 - 3 1 -
Braking Selection 1 - 3 1 -
3 - Golf Mild Hills
Speed 10.2 - 14.8 13.8 mph
Accel Selection 1 - 3 2 -
Braking Selection 1 - 3 2 -
4 - Golf Steep Hills
Speed 10.2 - 14.8 12.8 mph
Accel Selection 1 - 3 2 -
Braking Selection 1 - 3 3 -
5 - Freedom
Speed 14.5 - 19.5 18.5 mph
Accel Selection 1 - 2 1 -
Braking Selection 1 - 2 1 -
Monitor
Battery
Amp Hours 0 - 100000 AmpHr
Battery Voltage 0 - 100 V
Elasped Meters Amp Hours Trip 0 - 100000 AmpHr
Vehicle
Speed 0 - 25 mph
Odometer 0 - 100000 miles
Hour Meter 0 - 100000 Hrs
I / O
Throttle 0 - 100 %
Speed Pulses ON / OFF -
Pers. Input 0 ON / OFF -
Pers. Input 1 ON / OFF -
Foot Input ON / OFF -
Key Input ON / OFF -
Forward Input ON / OFF -
Reverse Input ON / OFF -
Charger Inhibit ON / OFF -
Main Cont Driver ON / OFF -
Controller
Profile 1 - 5
Temperature -55 - 125 C
Arm Current -300 - 300 A
Field Current 0 - 20 A
Armature PWM 0 - 100 %
Field PWM 0 - 100 %
Fault Counters
Throttle Fault 0 - 255 -
Low Battery Voltage 0 - 255
Overvoltage 0 - 255
Thermal Cutback 0 - 255
HPD 0 - 255 -
Main Drvr OverCurrent 0 - 255 -
Neg la 250 0 - 255 -
Neg la 300 0 - 255 -
