Page T-1
Repair and Service Manual
GENERAL SPECIFICATIONS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
TYPE: ELECTRIC POWERED PERSONNEL CARRIER
Part No:. 619212
TruCourse Technology:
Programmable to multiple vehcle terrains, with expanded regenerative braking function, and vehicle charger lockout
z Solid State continuously variable seperately excited speed controller z Six, 8 Volt Deep Cycle Batteries
z Dash mounted direction selector switch (Forward-Neutral-Reverse) z Full torque, reduced speed reverse
z Anti-roll back, walkaway braking and alarm z Inductive throttle sensor
z Programmable regenerative braking, acceleration and speed z Handheld vehicle diagnostics and rounds tracking
Battery Charger: PowerWise 48QE high frequency, fully line compensating. 10ft (3m) DC Cord. Underwriters Lab. (U.L.) Listed, (C.S.A. Certified)
z Input: 120 Volts AC, 50/60Hz, 8 amps z Output: 48 Volts DC at 13 amps
Motor: 48 Volt DC shunt wound, brazed armature, solid copper windings
Drive Train: Direct motor shaft connected to transaxle pinion shaft
Electrical System: 48 Volt DC, six, 8 volt deep cycle batteries (117 minute minimum, 170 amp-hour @ 20 hr. discharge rate)
Transaxle: Differential with helical gears
Brakes: Dual rear wheel mechanical self-adjusting drum brakes. Automatic single point park brake release with self-compensating system
Capacity: Seating for 4 persons. Rear Seat converts to Cargo Bed
Performance
Overall Length 108.5 in (276 cm) Seating Capacity 4 Person
Overall Width 48.5 in (123 cm) Dry Weight 685 lb (311kg) (Without Batteries)
Overall Height (No Canopy)
52.5 in (133 cm) (Top of steering wheel)
Curb Weight 1050 lb (477kg) Trojan T-875
Overall Height (With Canopy) 82.0 in (208 cm) (Top of Sun Canopy) Vehicle load capacity 800 lb (363 kg)
65.5 in (166 cm) Outside Clearance Circle 19 ft (5.8 m)
Front Wheel Track 38.0 in (97 cm) Intersecting Aisle Clearance N/A
Rear Wheel Track 38.5 in (98 cm) Speed (Level Ground)
17.5 mph ± 0.5 mph (28.2 kph ± 0.8 kph)
Gnd Clearance @ Differential 5.5 in (14 cm) Towing Capacity N/A
Load Bed Width 40.0 in (102 cm) Steering & Suspension
32.0 in (81 cm) Steering Self-compensating rack and pinion
Vehicle Power Front Suspension Leaf springs with hydraulic shock absorbers
Power Source 48 Volts DC
Leaf springs with hydraulic shock absorbers
Motor Type Shunt Wound Service Brake Rear wheel mechanical self-adjusting drum
3.0 HP (2.2kW) Continuous Parking Brake Self-compensating, single point engagement
Electrical System 48 Volt Front Tires Trail Wolf 20 x 11 - 10 Uni-directional
Batteries (Qty, Type) Six, 8 Volt Deep Cycle Rear Tires Trail Wolf 20 x 11 - 10 Uni-directional
Key or Pedal Start Pedal Start
Battery Charger 48 VDC PowerWise™ QE, 120 VAC, UL/CSA Frame Welded steel with DuraShield™ powder coat
Speed Controller
250 Amp Solid State Controller
Front Body & Finish Injection Molded TPO
Drive Train Motor Shaft Direct Drive Rear Body & Finish Injection molded TPO
Transaxle Differential with helical gears Standard Color Patriot Blue
Gear Selection Dash Mounted Forward-Neutral-Reverse
Rear Axle Ratio 14.76:1
Some items shown may be optional equipment
