Page T-3
Repair and Service Manual
GENERAL SPECIFICATIONS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 2 Vehicle Dimensions, Incline Specifications and Turning Clearance Diameter
RECOMMENDED MAX SIDE TILT
25% or 14
o
MAX
RECOMMENDED MAX RAMP GRADE
25% or 14
o
MAX
TURNING CLEARANCE DIAMETER
SHUTTLE 4X
20.5 ft (6.3 m)
