Custom Audio Electronics PLUS4 User Manual

PLUS4 9-42 V
1
2
3
4 5
POWER SUPPLY
Tripolar female connector
J2
1 GND
2 +VRE
3 GND
4 Frame GND
5 Frame GND

Tripolar male connector
Power supply cable
+24 Vn.c.
GND
ATTENTION:
Respect power supply polarity.
12
3 4
USB INTERFACE
Female USB type B connector
J5
1 VPLUG (in)
2 D0- (in/out)
3 D0+ (in/out)
4 GND
SH1 GND
SH2 GND
28

Custom Audio Electronics PLUS4 Specifications

General

Brand	Custom Audio Electronics
Model	PLUS4
Category	Printer
Language	English
