This function will display the axes positions on the Bend Numerical Page.
• When set to no, the position of axes Y1, X and R is displayed during the beam’s
movements.
• When set to yes1, the positions of the axes (Y1, Y2, X and R) are displayed during
their respective movements.
• When set to yes2, the positions of the axes (Y1, Y2, X and R) are constantly
displayed under their respective set-point values.
This parameter, when activated, lets the operator see the state of the part before and after
the bend in the Bend Sequencing page.
Touching Materials opens the Materials page, where the default characteristics for each
material can be changed, or a new material can be configured.
To be allowed to access the Materials page, a level 2 password is required.
The Materials page displays:
• Material: Selected material (here Steel).
• Default thickness for the material.
• Default sigma: Default sigma for the material (here 45).
• Displayed: If the material will be available to be selected for use (here yes).
