5. Touching the values next to any axes allows entering a correction.
The axes corrections can be positive or negative and will be added to the axes
positions.
The back-gauge positions corrections can also directly be made on the Bend
Numerical Page.
Back gauge
Correction
Back gauge (X axis) position
correction value
Back gauge (R axis) height
correction value
