Tools management allows the creation and configuration on the VisiTouch of the tools to
be used on the machine. These tools are then considered in bend calculations.
Once a punch and die are created and selected, you can select the bend angle you require
as well as the flange length (L). The VisiTouch then calculates the positions for axes X and
Y for the bend.
Bend Numerical Page →
SETTING INSTRUCTIONS:
To select a punch, simply browse through the existing punches in your library using the
arrows buttons, and then return to Bend Numerical Page.
To Next Page
